Wave, Wall, 90cm, Black Glass, BODY ONLY
Model: AWAM90ABX
Authorized Dealer
Loading...
Authorized Dealer
Wave, Wall, 90cm, Black Glass, BODY ONLY
Model: AWAM90ABXQuick Specs
Width
35.375"
Depth
16.25"
Height
18.875"
RPM
-1.0
Energy
NO
Wave, Wall, 90cm, Black Glass, BODY ONLY is backordered and will ship as soon as it is back in stock.
We’ll confirm availability & delivery timing before processing your payment.
Available to Order
Regular price
$1,881.00
Unit price
/
Unavailable
SERVICES AVAILABLE
Selection will add
$0.00
to the price
Couldn't load pickup availability
Quick Specs
Width
35.375"
Depth
16.25"
Height
18.875"
RPM
-1.0
Energy Star Rated
NO
- Includes wireless remote control
- Our wireless remote control places the hoods operations at your fingertips from anywhere in the kitchen.
- Dual capture zones
- Cooking contaminates are pulled in through two entry points to improve capture performance.
- Capacitive touch controls
- LED light strip
- This multi-level LED light strip ensures even, warm white lighting while fully illuminating the cooking area.
- Optional Ductless Recirculating Kit
- Ductless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen.
- Optional extension duct cover kit
- Includes wireless remote control
- Dual capture zones
- Capacitive touch controls
- LED light strip
- Optional Ductless Recirculating Kit
- Optional extension duct cover kit
Wave, Wall, 90cm, Black Glass, BODY ONLY
| Brand | Zephyr |
| Manufacturer | Zephyr |
| Category | Range Hood |
| Sub-Category | Wall |
| Vent Type | Convertible |
| UPC | 646328004339 |
| GTIN | 00646328004339 |
| Country of Origin | Italy |
| Model Group | AWA-A |
| Model Name | Wave |
| Collection | Designer Collection |
| Blower Included | No |
| Internal Blower 1 CFM | 290 |
| Internal Blower 1 Min. Sones | 1.4 |
| Internal Blower 1 Max Sones | 3 |
| Internal Blower 2 CFM | 600 |
| Internal Blower 2 Max Sones | 6 |
| In-Line Blower CFM | 1000 |
| External Blower CFM | 1000 |
| Installation Type | Wall |
| Installation Type | Wall |
| For Outdoor Use | No |
| Color | Stainless Steel + Black |
| Controls Type | Capacitive Touch |
| Blower Speeds | 3 |
| Automatic Delay-Off | Yes |
| Clean Air Function | Yes |
| Lighting Type | LED |
| Lights Quantity | 1 |
| Watts Per Bulb | 8.5 |
| Lights Levels | 3 |
| Grease Filter Type | Mesh |
| Compatible Mesh or Baffle Filter Part Number | 50200057 |
| Duct Discharge | Vertical or Horizontal |
| Duct Size; Horizontal; IN | 6, 8 |
| Duct Size; Vertical; IN | 6, 8 |
| Mounting Height Above Cooktop; IN | 22 - 32 |
| Voltage | 120 |
| Maximum Amperage | 6.45 |
| ADA Compliant | Yes |
| Warranty Parts / Labor | 1 / 1 |
| Compatible Appliances | ZRC-00WA, Z1C-00IN, MUA006A, MUA008A, Z0F-01AC |
| Bluetooth Connected | No |
| Wi-Fi Connected | No |
| Remote Included | Yes |
| Remote Optional | No |
| Energy Star Certified | No |
| Alexa & Google Home Compatible | No |
| CEC Title 20 Compliant | Yes |
| Primary Material | Steel |
| Nominal Width; IN | 36 |
| Net Width; IN | 35.375 |
| Net Depth; IN | 16.25 |
| Net Height; IN | 18.875 |
| Weight; LBS | 58 |
| Ceiling Height Minimum | 8 ft. |
| Ceiling Height Maximum | 10 ft. |
| Shipping Length; IN | 26.37 |
| Shipping Width; IN | 37.8 |
| Shipping Height; IN | 22.04 |
| Shipping Weight; LBS | 64.7 |
| Shipping Method | LTL |
| Freight Class | 300 |
| Duct Type | Vertical |
| Duct Type | Vertical |
- Includes wireless remote control
- Dual capture zones
- Capacitive touch controls
- LED light strip
- Optional Ductless Recirculating Kit
- Optional extension duct cover kit
 | |
|---|---|
| Design Features | |
Key Features |
|
Product Type |
|
| Dimensions & Capacity | |
Width |
|
Depth |
|
Height |
|
| Appearance & Specifications | |
Configuration |
|
Color |
|
Energy Star Rated |
|
