Range Stainless steel CPF36UGMX
Model CPF36UGMX
Range Stainless steel CPF36UGMX
Model CPF36UGMXQuick Specs
Range Stainless steel CPF36UGMX is backordered and will ship as soon as it is back in stock.
SERVICES AVAILABLE
Couldn't load pickup availability
Quick Specs
- Product family: Range
- Range size: 36"
- Aesthetics: Portofino
- Color: Stainless steel
- Main oven: Thermo-ventilated
(P)(B)PORTOFINO STYLE(/B)(/P)(P)Stainless steel control knobs(/P)(P)(B)Thermoseal cavity, energy efficiency best-in-class(/B) (/P)(P)(B)Soft close oven door(/B)(/P)(P)Full-width continuous grates(/P)(P)Push-pull stainless steel storage compartment(/P)(P)(B)MULTIFUNCTION ELECTRIC OVEN:(/B)(/P)(P)10 cooking modes including Pizza Function (/P)(P)Vapor-clean function(/P)(P)Programmable timer with touch display (/P)(P)Adjustable thermostat 120(degree) - 500(degree)F (/P)(P)Air-cooled triple-glazed removable door (/P)(P)(B)True European triple convection(/B)(/P)(P)Oven capacity: 4.5 cu. ft.(/P)(P)(B)Ever Clean enameled interior cavity(/B)(/P)(P)5 shelf positions(/P)(P)2 x halogen oven lights(/P)(P)Bake element 1.7kW(/P)(P)Broil element 2.9kW(/P)(P)Convection element 1.5kW(/P)(P)(B)GAS RANGETOP:(/B)(/P)(P)5 gas burners(/P)(P)Center-rear 4500 BTUs(/P)(P)Center-front 10500 BTUs(/P)(P)Right-rear 12000 BTUs(/P)(P)Right-front 8000 BTUs(/P)(P)(B)Left double-inset super burner 20000 BTUs(/B)(/P)(P)Heavy-duty cast iron grates(/P)(P)Automatic electric ignition(/P)(P)LP gas conversion kit included(/P)(P)(B)SAFETY:(/B)(/P)(P)Gas safety valves(/P)(P)Air-cooled door to prevent overheating(/P)(P)Connected load nominal power: 240/120V - 17 Amps(/P)(P)Voltage rating: 240/120V 60Hz(/P)(P)(B)ACCESSORIES INCLUDED:(/B)(/P)(P)1 wok ring(/P)(P)1 rotisserie kit(/P)(P)1 deep oven tray(/P)(P)1 total-extraction telescopic guide (/P)(P)2 chrome shelves(/P)(P)1 black toe kick(/P)
| Type | |
| Product family | Range |
| Range size | 36" |
| Range fuel | Dual-fuel |
| N. of ovens | 1 |
| Main oven | Thermo-ventilated |
| Cleaning system | VaporClean |
| EAN code | 8017709250683 |
| Aesthetic | |
| Color | Stainless steel |
| Finishing | Satin |
| Aesthetics | Portofino |
| Design | Flush mounted |
| Material | Stainless steel |
| Door | With frame |
| Control panel finish | Fingerprint-proof stainless steel |
| Cooktop color | Stainless steel |
| Handle | Portofino |
| Controls color | Stainless steel |
| Upstand | Yes |
| Display | Touch |
| Grates | Cast Iron |
| Door glass type | Gray |
| Handle color | Brushed stainless steel |
| Control knobs | Portofino |
| No. of controls | 8 |
| Feet | Stainless steel |
| Plinth | Black |
| Storage compartment | Push-pull |
| Main oven options | |
| Timer | Yes |
| End-of-cooking alarm | Yes |
| Minimum Temperature | 120 °F |
| Maximum temperature | 500 °F |
| Cooktop technical features | |
| Cooking zones | 5 |
| Zone 1 - Type | Gas - Dual ultra-rapid |
| Zone 2 - Type | Gas - AUX |
| Zone 3 - Type | Gas - Rapid |
| Zone 4 - Type | Gas - Rapid |
| Zone 5 - Type | Gas - Semi-rapid |
| Zone 1 - Power | 5.86 kW |
| Zone 1 - Power | 20000 BTU |
| Zone 2 - Power | 1.31 kW |
| Zone 2 - Power | 4500 BTU |
| Zone 3 - Power | 3.08 kW |
| Zone 3 - Power | 10500 BTU |
| Zone 4 - Power | 3.51 kW |
| Zone 4 - Power | 12000 BTU |
| Zone 5 - Power | 2.34 kW |
| Zone 5 - Power | 8000 BTU |
| Burners type | Standard |
| Burner caps | Enameled matte black |
| Automatic gas ignition | Yes |
| Gas safety valves | Yes |
| Main Oven Technical Features | |
| Volume | 4.45 cu. ft. |
| Cavity material | EverClean enamel |
| No. of shelves | 5 |
| Shelves type | Metal racks |
| No. of lights | 2 |
| Light type | Halogen |
| Light Power | 40 W |
| Fan number | 3 |
| Time setting | Start and end |
| Door opening | Drop-down |
| Light on when door is open | Yes |
| Removable door | Yes |
| Full-glass inner door | Yes |
| Removable inner door | Yes |
| Total no. of door glasses | 3 |
| No.of thermo-reflective door glasses | 2 |
| Safety thermostat | Yes |
| Cooling system | Tangential |
| Grill type | Electric |
| Grill power | 1700 W |
| Large grill - Power | 2900 W |
| Bottom heating element - Power | 1700 W |
| Upper heating element - Power | 1200 W |
| Circular heating element - Power | 2 x 1550 W |
| Soft Close system | Yes |
| Temperature control | Electro-mechanical |
| Electrical Connection | |
| Electrical connection rating | 3800 W |
| Current | 20 A |
| Circuit breaker | 20 A |
| Voltage | 240/208 V |
| Frequency | 60 Hz |
| Power cord length | 47 1/4 " |
| Type of electric cable installed | Yes, Double phase |
| Gas Connection | |
| Gas Type | G20/G25 - 20/25 mbar |
| Logistic Information | |
| Dimensions | 915x912x635 mm |
| Width | 35 7/8 " |
| Height | 36 1/16 " |
| Depth | 25 1/16 " |
| Packaged dimensions | 976X950X670 mm |
| Gross weight | 261 lbs |
| Net weight | 226 lbs |
| Packaged width | 37 3/8 " |
| Packaged depth | 26 3/8 " |
| Packaged height | 38 7/16 " |
| Maximum stackability | 5 |
| Packaging | Cardboard box |
| Packaging composition - Paper | 13 lbs |
| Packaging composition - Polystyrene | 14 lbs |
| Packaging composition - Wood | 7 lbs |
| Packaging composition - Plastics | 1 lbs |
| Accessories Included | |
| Other gas nozzles included | G30 LPG liquid gas |
| Accessories included for main oven and cooktop | |
| Cast iron wok support | 1 |
| TOP Oven grid with back stop | 2 |
| 1.6"-deep tray | 1 |
| Telescopic Guide rails, total Extraction | 1 |
