Range Yellow CPF36UGMYW
Model CPF36UGMYW
Authorized Dealer
1
of
6
Loading...
Authorized Dealer
Range Yellow CPF36UGMYW
Model CPF36UGMYWQuick Specs
Depth
25.06"
Height
36.06"
Sabbath
NO
ADA
NO
Wifi
NO
Burner
Sealed
Storage
YES
Warming
NO
Color
Range Yellow CPF36UGMYW is backordered and will ship as soon as it is back in stock.
Regular price
$3,568.57
Unit price
/
Unavailable
Available to Order
SERVICES AVAILABLE
Selection will add
$0.00
to the price
Couldn't load pickup availability
Quick Specs
Depth
25.06"
Height
36.06"
Sabbath Mode
NO
ADA
NO
Wifi Connected
NO
Burner Type
Sealed
Cooking has Storage Drawer
YES
Cooking has Warning Drawer
NO
Cooking oven number of burners
5
Continuous Grate
YES
Convection
YES
Self Clean
NO
Oven Rack Type
ROLLER
Downdraft Ventilation
NO
Drawer Proof Mode
NO
Dual Fuel
YES
Oven Ignition Type
ELECTRONIC
- Easy and intuitive timer setting with a single touch
- New cooling system with tangential fan and airflow from the door to the splashback
- The best cooking performances guaranteed by ventilated circular flow. - True-convection
- Gas provides permanent control of the heat source and the temperature change is immediate - Gas hob
- By inserting water into a recess at the bottom of the cavity, steam is generated, which softens the residue and facilitates its removal - Vapor Clean
- The door is equipped with a specific system for silent closing
- More space thanks to the lower push-pull compartment, ideal for storing accessories or cooking utensils
True-convection
| General information | |
| Product family | Range |
| Range size | 36" |
| Range type | Dual fuel |
| Cooktop | Mixed |
| N. of ovens | 1 |
| Main oven | Thermo-ventilated |
| EAN code | 8017709254049 |
| General information | |
| Installation positioning of the appliance | Free-standing, Class 1, Built-in, Class 2-1 norm UNI EN 30-1-1 |
| Cleaning system | VaporClean |
| Aesthetic | |
| Color | Yellow |
| Design | Flush mounted |
| Aesthetics | Portofino |
| Control panel finish | Metal enameled |
| Material | Painted metal |
| Upstand | Yes |
| Cooktop color | Stainless steel |
| Grates | Cast Iron |
| Control setting type | Control knobs |
| Control knobs | Portofino |
| Controls color | Stainless steel |
| No. of controls | 8 |
| Display | Touch |
| Door | With frame |
| Door glass type | Gray |
| Handle | Portofino |
| Handle color | Colored |
| Storage compartment | Push-pull |
| Feet | Stainless steel |
| Plinth | Black |
| Main oven options | |
| Timer | Yes |
| End-of-cooking alarm | Yes |
| Minimum Temperature | 120 °F |
| Maximum temperature | 500 °F |
| Cooktop technical features | |
| Cooking zones | 5 |
| Zone 1 - Position | Left |
| Zone 2 - Position | Rear-center |
| Zone 3 - Position | Front-center |
| Zone 4 - Position | Rear-right |
| Zone 5 - Position | Front-right |
| Zone 1 - Type | Gas - Dual ultra-rapid |
| Zone 2 - Type | Gas - AUX |
| Zone 3 - Type | Gas - Rapid |
| Zone 4 - Type | Gas - Rapid |
| Zone 5 - Type | Gas - Semi-rapid |
| Zone 1 - Power | 5860 W |
| Zone 2 - Power | 1310 W |
| Zone 3 - Power | 3080 W |
| Zone 4 - Power | 3510 W |
| Zone 5 - Power | 2340 W |
| Burners type | Standard |
| Burner caps | Enameled matte black |
| Automatic gas ignition | Yes |
| Gas safety valves | Yes |
| Main Oven Technical Features | |
| Volume | 0.16 cu. ft. |
| Cavity material | EverClean enamel |
| No. of shelves | 5 |
| Shelves type | Metal racks |
| No. of lights | 2 |
| Light type | Halogen |
| Light Power | 40 W |
| Fan number | 3 |
| Time setting | Start and end |
| Door opening | Drop-down |
| Light on when door is open | Yes |
| Removable door | Yes |
| Full-glass inner door | Yes |
| Removable inner door | Yes |
| Total no. of door glasses | 3 |
| No.of thermo-reflective door glasses | 2 |
| Safety thermostat | Yes |
| Cooling system | Tangential |
| Grill type | Electric |
| Tiliting grill | Yes |
| Grill power | 1700 W |
| Large grill - Power | 2900 W |
| Bottom heating element - Power | 1700 W |
| Upper heating element - Power | 1200 W |
| Circular heating element - Power | 2 x 1550 W |
| Soft Close system | Yes |
| Temperature control | Electro-mechanical |
| Electrical Connection | |
| Electrical connection rating | 3800 W |
| Current | 20 A |
| Voltage | 240/208 V |
| Frequency | 60 Hz |
| Power cord length | 47 1/4 " |
| Gas Connection | |
| Gas Type | G20/G25 - 20/25 mbar |
| Logistic Information | |
| Dimensions | 915x912x635 mm |
| Width | 35 7/8 " |
| Height | 36 1/16 " |
| Depth | 25 1/16 " |
| Packaged dimensions | 976X950X670 mm |
| Gross weight | 261 lbs |
| Net weight | 230 lbs |
| Packaged width | 37 3/8 " |
| Packaged depth | 26 3/8 " |
| Packaged height | 38 7/16 " |
| Packaging | Cardboard box |
| Packaging composition - Paper | 11 lbs |
| Packaging composition - Polystyrene | 13 lbs |
| Packaging composition - Wood | 7 lbs |
| Packaging composition - Plastics | 1 lbs |
| Included accessories | |
| Cast iron wok support | 1 |
| TOP Oven grid with back stop | 2 |
| 1.6"-deep tray | 1 |
| Telescopic Guide rails, total Extraction | 1 |
| Accessories Included | |
| Other gas nozzles included | G30 LPG liquid gas |
- Easy and intuitive timer setting with a single touch
- New cooling system with tangential fan and airflow from the door to the splashback
- The best cooking performances guaranteed by ventilated circular flow. - True-convection
- Gas provides permanent control of the heat source and the temperature change is immediate - Gas hob
- By inserting water into a recess at the bottom of the cavity, steam is generated, which softens the residue and facilitates its removal - Vapor Clean
- The door is equipped with a specific system for silent closing
- More space thanks to the lower push-pull compartment, ideal for storing accessories or cooking utensils
