Breeze I, UC, 36", Wht, 250 CFM
Model: AK1136W
Authorized Dealer
1
of
5
Loading...
Authorized Dealer
Breeze I, UC, 36", Wht, 250 CFM
Model: AK1136WQuick Specs
Depth
20.25
Height
5.5
Discontinued
Regular price
$297.00
Unit price
/
Unavailable
Warranty
Selected warranty added with 'Add to Cart'.
SERVICES AVAILABLE
Selected service(s) added with 'Add to Cart'.
Couldn't load pickup availability
Quick Specs
Depth
20.25
Height
5.5
- Value driven
- Low-profile body
- Low-profile body for a minimalist appearance.
- Extra-wide mesh filters
- High quality mesh filters with an increased width for improved capture and performance.
- Optional Ductless Recirculating Kit
- Ductless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen.
- Multiple color options
- Multiple colors available to match your kitchen decor.
- Value driven
- Low-profile body
- Extra-wide mesh filters
- Optional Ductless Recirculating Kit
- Multiple color options
Breeze I, UC, 36", Wht, 250 CFM
| Brand | Zephyr |
| Manufacturer | Zephyr |
| Category | Range Hood |
| Sub-Category | Under Cabinet |
| Vent Type | Convertible |
| UPC | 646328113642 |
| GTIN | 00646328113642 |
| Country of Origin | Taiwan |
| Model Group | AK11 |
| Model Name | Breeze I Under-Cabinet |
| Collection | Core Collection |
| Replacement Model | AK1136BW |
| Blower Included | Yes |
| Internal Blower 1 CFM | 250 |
| Internal Blower 1 Min. Sones | 1.8 |
| Internal Blower 1 Max Sones | 3.5 |
| Minimum CFM | 150 |
| Installation Type | Under Cabinet |
| Installation Type | Under Cabinet |
| For Outdoor Use | No |
| Color | White |
| Controls Type | Mechanical Slide |
| Blower Speeds | 3 |
| Automatic Delay-Off | No |
| Clean Air Function | No |
| Lighting Type | Halogen |
| Lights Quantity | 2 |
| Watts Per Bulb | 35 |
| Lights Levels | 2 |
| Grease Filter Type | Mesh |
| Compatible Mesh or Baffle Filter Part Number | 50200012 |
| Duct Discharge | Vertical or Horizontal |
| Duct Size; Horizontal; IN | 3.25 x 10 |
| Duct Size; Vertical; IN | 3.25 x 10 |
| Mounting Height Above Cooktop; IN | 24 - 32 |
| Voltage | 120 |
| Maximum Amperage | 1.3 |
| ADA Compliant | No |
| Warranty Parts / Labor | 3 / 1 |
| Compatible Appliances | 0AK11-21001, Z0B0040, 0AK11-20001 |
| Bluetooth Connected | No |
| Wi-Fi Connected | No |
| Remote Included | No |
| Remote Optional | No |
| Energy Star Certified | No |
| Alexa & Google Home Compatible | No |
| CEC Title 20 Compliant | Yes |
| Primary Material | Steel |
| Wattage | 156 |
| Certification | UL |
| Nominal Width; IN | 36 |
| Net Width; IN | 35.9375 |
| Net Depth; IN | 20.25 |
| Net Height; IN | 5.5 |
| Weight; LBS | 20.4 |
| Ceiling Height Minimum | 8 ft. |
| Ceiling Height Maximum | 12 ft. |
| Shipping Length; IN | 39.57 |
| Shipping Width; IN | 9.45 |
| Shipping Height; IN | 24.61 |
| Shipping Weight; LBS | 27.1 |
| Shipping Method | Small Parcel |
| Freight Class | 175 |
| Duct Type | Vertical |
| Duct Type | Vertical |
