33" CCC 600/395 CFM Pro Insert For Custom Built Hood Italian Made Stainless
Model: XOI33SC
Authorized Dealer
1
of
6
Loading...
Authorized Dealer
33" CCC 600/395 CFM Pro Insert For Custom Built Hood Italian Made Stainless
Model: XOI33SCQuick Specs
Width
33.75"
Depth
18 7/16"
Height
11 1/2"
Energy
NO
33" CCC 600/395 CFM Pro Insert For Custom Built Hood Italian Made Stainless is backordered and will ship as soon as it is back in stock.
Estimated to ship in 2-4 days
In Stock
Add to cart to see lower price
Sale Price
$949.00
$1,190.00
You save 20%
SERVICES AVAILABLE
Selection will add
$0.00
to the price
Couldn't load pickup availability
Quick Specs
Width
33.75"
Depth
18 7/16"
Height
11 1/2"
Energy Star Rated
NO
- Backlit Electronic 4 Speed Control with Power Boost
- CCC Code Compliance Control - permanently set blower to 395 or 600 CFM to meet local codes
- High Efficiency 3000K LED lights brightly illuminate the cooktop
- Dishwasher Safe Pro Style Stainless Baffle Filters for efficient filtration
- 5 Minute Delay Shutoff Timer
- Convertible 6" Vertical Duct or Ductless Recirculating (Kit Sold Separately)
- XO quality and performance for your custom built-ins
- Made In Italy
- 2 year limited parts and labor warranty for the original owner
- NOTE *When CCC(TM) is enabled the number of fan speeds will be reduced to maximum 3 speeds
This XOI model series is available in two different depths and three different flow rates to better satisfy your needs. This integrated blower allows you to match your custom hood to your kitchen. Simple and affordable, XOI is easy to install. Designed and crafted in Italy for the ultimate in fit and finish.
| Collection | Fabriano Collection |
| Origin | Italy |
| UPC | 814830012788 |
| Height | 11 1/2" |
| Width | 33 3/4" |
| Depth | 18 7/16" |
| Cut-Out Depth (in.) | 16 3/8" |
| Cut-Out Height (in.) | 11 1/2" |
| Cut-Out Width (in.) | 32 1/2" |
| Dimensions D x W x H | 18 7/16" x 33 3/4" x 11 1/2" |
| Product Weight | 28.6 |
| Warranty 1 Explained | 90 Day Love It Or Leave It |
| Warranty 2 Explained | 2 Year Limited Material And Workmanship for the original owner |
| ADA Compatible | No |
| Certification | UL |
| Prop 65 | Yes |
| Freight Class | 85 |
| Shipping Weight | 44 |
| Carton Height | 12" |
| Carton Width | 40" |
| Carton Depth | 18" |
| Shipping Method | LTL |
| Amperage | 3.6 Amps |
| Electrical | 120V - 60Hz - 3.6 Amps |
| Frequency (Hz) | 60 Hz |
| Voltage (volts) | 120 VAC |
| Wattage (watts) | 430 watts |
| Appliance Type | Range Hoods |
| CCC Code Compliance Control | Yes |
| CFM @ Speed 1 | 160 |
| CFM @ Speed 2 | 250 |
| CFM @ Speed 3 | 395 |
| CFM @ Speed 4 | 600 |
| Color/Finish | Stainless |
| Commerical/Residential | Residential |
| Control Type | Backlit LED |
| Cooktop Lights | Twin LED Lights |
| Duct Size | 6" Dia. |
| Ductless Convertible | Ducted or Convertible |
| Filter Type | Dishwasher Safe Pro Stainless Steel Baffles |
| Install Type | Insert |
| Installation Type | Insert |
| LIght Colors | White |
| Light Type | Twin LED Lights |
| Lighting Features | 3000K LED |
| Maximum Air Flow Capacity CFM) | 600/395 |
| Minimum Air Flow Capacity (CFM) | 160 |
| Mounting Height Above Cooktop | 27" - 32" |
| Number of Light Bulbs | 2 |
| Number of Speeds | 4 |
| Returnable | No |
| Sones @ Speed 1 | 1 |
| Sones @ Speed 2 | 2.5 |
| Sones @ Speed 3 | 4 |
| Sones @ Speed 4 | 6.5 |
| Vent Location | Top |
| Vent Material | Metal |
| Wireless Compatibility | No |
| Control Lighting | Blue Backlit |
| Controls | Code Compliance Electronic Controls |
| Location | Indoor |
| Sound Level | 1.0-6.5 Sones |
| Assembled Depth (in.) | No |
- Backlit Electronic 4 Speed Control with Power Boost
- CCC Code Compliance Control - permanently set blower to 395 or 600 CFM to meet local codes
- High Efficiency 3000K LED lights brightly illuminate the cooktop
- Dishwasher Safe Pro Style Stainless Baffle Filters for efficient filtration
- 5 Minute Delay Shutoff Timer
- Convertible 6" Vertical Duct or Ductless Recirculating (Kit Sold Separately)
- XO quality and performance for your custom built-ins
- Made In Italy
- 2 year limited parts and labor warranty for the original owner
- NOTE *When CCC(TM) is enabled the number of fan speeds will be reduced to maximum 3 speeds
 | |
|---|---|
