28 3/8" 300 CFM Wall Mount Liner Insert Stainless Steel
Model BH128SLDSS
Authorized Dealer
Loading...
Authorized Dealer
28 3/8" 300 CFM Wall Mount Liner Insert Stainless Steel
Model BH128SLDSSQuick Specs
Width
28.37"
Depth
19.25"
Height
12"
Energy
NO
28 3/8" 300 CFM Wall Mount Liner Insert Stainless Steel is backordered and will ship as soon as it is back in stock.
Ships Out Within: 2 - 4 Business Days
Shipping Date By: 06/29/2026
Sale Price
Sale price
$1,200.23
Regular price
$1,445.00
Unit price
/
Unavailable
You save 16%
SERVICES AVAILABLE
Selection will add
$0.00
to the price
Couldn't load pickup availability
Quick Specs
Width
28.37"
Depth
19.25"
Height
12"
Energy Star Rated
NO
- Quietest at all speeds
- Easiest to Clean
- Patented Filterless Design
- Inherently Fire Safe
- 5 Year Warranty
- SensaSource(R) heat detection
The standard ventilation of the BHSLD model is intended for use over standard cooking equipment. Click on the models for a list of our base model numbers for standard sizes; simply select the model you need, and then specify the finish [painted or stainless steel]. All liners in this series are 19 1/4" deep. Recommended mounting height is 24" - 27" above the cooking surface. All Vent-A-Hood products are suitable for use in damp locations [outdoor applications such as a covered patio] when installed in a GFCI protected branch circuit.(BR)
| WIDTH : | 28 3/8" |
| DEPTH : | 19 1/4" |
| HEIGHT : | 12" |
| CFM : | 300 |
| SONES : | 5.4 |
| Amps : | 2.5 |
| Num. Lights : | 2 |
| ELECTRICAL/MECHANICAL SPECIFICATIONS FOR BLOWER UNIT | |
| Model | B100 Single |
| Volts | 115 |
| Amps+ | 2.5 |
| Hz | 60 |
| RPM | 1550 |
| CFM [email protected]" | 300 |
| Equiv. CFM$ | 450 |
| CFM [email protected]" | 273 |
| CFM [email protected]" | 245 |
| CFM [email protected]" | 225 |
| Min. Round Duct Size | 6" (28 sq. in.) |
| Sones# | 5.4 |
- Quietest at all speeds
- Easiest to Clean
- Patented Filterless Design
- Inherently Fire Safe
- 5 Year Warranty
- SensaSource(R) heat detection
 | |
|---|---|
| Design Features | |
Key Features |
|
Product Type |
|
| Dimensions & Capacity | |
Width |
|
Depth |
|
Height |
|
| Appearance & Specifications | |
Configuration |
|
Color |
|
Energy Star Rated |
|
