24" Wide Built-in Refrigerator-freezer, ADA Compliant
Model AL650WBI
Authorized Dealer
1
of
4
Loading...
Authorized Dealer
24" Wide Built-in Refrigerator-freezer, ADA Compliant
Model AL650WBIQuick Specs
Width
23.63"
Depth
27.75"
Height
32.25"
Sabbath
NO
Fresh
5.1
Cu Ft
5.1
Size
5.1
Shelves
3
24" Wide Built-in Refrigerator-freezer, ADA Compliant is backordered and will ship as soon as it is back in stock.
This item qualifies for free delivery
Ships Out Within: 2 - 4 Business Days
Shipping Date By: 06/29/2026
Regular price
$1,416.06
Unit price
/
Unavailable
SERVICES AVAILABLE
Selection will add
$0.00
to the price
Couldn't load pickup availability
Quick Specs
Width
23.63"
Depth
27.75"
Height
32.25"
Sabbath Mode
NO
Fresh food Capacity
5.1
Capacity (cu ft.)
5.1
Refrigerator Size
5.1
Refrigerator number of Shelves
3
ADA
YES
Dispenser
NO
Icemaker
NO
Wifi Connected
NO
Counter Depth
NO
RPM
-1.0
Energy Star Rated
NO
- Undercounter Refrigerator-Freezer
- 24" wide refrigerator with freezer compartment sized to fit under ADA compliant counters
- Cycle defrost
- This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment
- ADA compliant
- 32" height to fit under lower ADA compliant counters
- Built-in capable
- Make the best use of space by installing your refrigerator under the counter and flush with other cabinets
- Fully finished white cabinet
- Allows the refrigerator-freezer to be used as a freestanding model
- Dual evaporator
- Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators
- Reversible door
- User-reversible door swing for added flexibility
- Adjustable shelves
- Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
- Adjustable thermostat
- Dial thermostat located inside for easy temperature management
- Door storage
- Store large bottles right on the door for easy access
- Clear crisper
- Get the longest life and best taste out of produce by storing in a convenient slide drawer
- Interior light
- Automatically illuminates when you open the door
- Hidden evaporator
- Cold wall design with hidden evaporator and seamless interior
- 100% CFC free
- Environmentally friendly design without ozone-damaging chemicals
- CARB Compliant
- Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations\t
- 24" wide refrigerator with freezer compartment sized to fit under ADA compliant counters
- This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment
- Get the longest life and best taste out of produce by storing in a convenient slide drawer
- Automatically illuminates when you open the door
- Cold wall design with hidden evaporator and seamless interior
- Environmentally friendly design without ozone-damaging chemicals
- Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
- 32" height to fit under lower ADA compliant counters
- Make the best use of space by installing your refrigerator under the counter and flush with other cabinets
- Allows the refrigerator-freezer to be used as a freestanding model
- Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators
- User-reversible door swing for added flexibility
- Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
- Dial thermostat located inside for easy temperature management
- Store large bottles right on the door for easy access
Summit Appliance manufactures a wide range of undercounter refrigeration for general purpose storage. The AL650BI Series includes refrigerator-freezers designed for optimum storage conditions in built-in applications under lower ADA compliant counters. At 32" high, the AL650WBI can be used built-in or freestanding in ADA compliant settings. The 24" footprint fits many popular cutouts while offering over 5 cu.ft. of storage capacity. This model has a white exterior finish and a user-reversible door swing. Inside, our unique dual evaporator system separately cools the refrigerator and freezer sections to ensure proper storage temperature. Cycle defrost operation reduces user maintenance in the automatic defrost fresh food section, with static manual defrost operation in the freezer compartment. Door storage provides easy access for tall bottles and small condiments. Additional features include adjustable shelves, a clear crisper, and automatic interior lighting. The AL650WBI has long proven itself to have one of the best temperature performance records in the industry. To see additional finish options on this unit, browse the full AL650BI Series. NOTE: This unit is designed for general purpose, medical, or commercial applications and does not meet DOE energy standards for residential use.
| Overview | |
| Nominal Height | 32.0" (81 cm) |
| Height of Cabinet | 32.0" (81 cm) |
| Height to Hinge Cap | 32.25" (82 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.63" (60 cm) |
| Nominal Depth | 24.0" (61 cm) |
| Depth | 23.5" (60 cm) |
| Depth with Handle | 24.75" (63 cm) |
| Depth with door at 90° | 45.63" (116 cm) |
| Capacity | 5.1 cu.ft. (144 L) |
| Defrost Type | Cycle |
| Door | White |
| Cabinet | White |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.4 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 100.0 lbs. (45 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101068213 |
| Refrigerator-Freezer | |
| Door Swing | RHD |
| Reversible | Yes |
| Adjustable Shelves | Yes |
| Crisper Qty | 1 |
| Crisper Finish | Transparent |
| Crisper Cover | Glass |
| Interior Light | Yes |
| Refrigerator - Interior Height | 19.5" (50 cm) |
| Refrigerator - Interior Width | 20.5" (52 cm) |
| Refrigerator - Interior Depth | 17.0" (43 cm) |
| Refrigerator - Shelf Type | Glass |
| Refrigerator - Shelf Qty | 3 |
| Refrigerator - Full Door Shelves | 3 |
| Freezer - Interior Height | 5.0" (13 cm) |
| Freezer - Interior Width | 19.0" (48 cm) |
| Freezer - Interior Depth | 11.5" (29 cm) |
| Thermostat Type | Dial |
| Fan Type | Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.92 oz. |
| High Side PSI | 180.0 |
| Low Side PSI | 80.0 |
| Level Legs | 4 |
| Compressor Step Height | 7.0" (18 cm) |
| Compressor Step Width | 20.5" (52 cm) |
| Compressor Step Depth | 5.0" (13 cm) |
