24" Wide Gas Range
Model TNM616R
24" Wide Gas Range
Model TNM616RQuick Specs
24" Wide Gas Range is backordered and will ship as soon as it is back in stock.
SERVICES AVAILABLE
Couldn't load pickup availability
Quick Specs
- Natural gas range; can be converted to LP Gas in our shop or ordered with KIT LP for conversion
- Apartment sized to fit in small or galley kitchens
- Easy cleanup on boil-overs and accidental spills
- Flat backguard can blend into other cabinetry and lets you choose your own wall design behind the range
- Black porcelain removable top and oven door
- Lower compartment for separate broiling with even heat distribution
- Two-piece porcelain broiler tray with grease well
- Gas spark ignition for automatic lighting of burners
- Smart design limits the depth and protects adjacent cabinets
- An elegant finish to the classic black exterior
SUMMIT PROFESSIONAL features a wide selection of slide-in ranges with full features for safe cooking and slim sizes to fit your kitchen. The TNM616R is a gas range conveniently sized at just 24 inches wide. Four sealed gas burners top the solid porcelain surface that's easy to clean and durable to use. A low stainless steel backguard and stainless steel manifold trim create a modern slide-in look. This model has a classic black oven made from complete porcelain with a recessed door to protect adjacent cabinets. Safety features include electronic ignition and an anti-tip bracket. The TNM616R has a broiler drawer below the oven for more even crisping with heat that spreads from the top down. Fully equipped for safe, easy, and quality cooking, our ranges are constructed with care in the U.S.A. and built to last in style.
| Overview | |
| Height of Cabinet | 36.0" (91 cm) |
| Width | 24.0" (61 cm) |
| Depth | 24.0" (61 cm) |
| Door | Black |
| Cabinet | Black |
| Weight | 125.0 lbs. (57 kg) |
| Shipping Weight | 150.0 lbs. (68 kg) |
| Parts & Labor Warranty | 1 Year |
| UPC | 761101013015 |
| Gas Range | |
| Ignition | Spark |
| LP Convertible | With Kit LP Accessory |
| Oven Capacity | 2.92 cu.ft |
| Cooktop Surface | Porcelain |
| Burner Type | Sealed |
| Number of Burners | 4 |
| Burner #1 BTU | 9000.0 |
| Burner #2 BTU | 9000.0 |
| Burner #3 BTU | 9000.0 |
| Burner #4 BTU | 9000.0 |
| Burner Controls | Dial |
| Oven Controls | Dial |
| Oven Interior Height | 14.0" (36 cm) |
| Oven Interior Width | 19.0" (48 cm) |
| Oven Interior Depth | 19.0" (48 cm) |
