20" Wide Built-in All-refrigerator, ADA Compliant
Model: FF511LBIMEDADA
20" Wide Built-in All-refrigerator, ADA Compliant
Model: FF511LBIMEDADAQuick Specs
20" Wide Built-in All-refrigerator, ADA Compliant is backordered and will ship as soon as it is back in stock.
SERVICES AVAILABLE
Couldn't load pickup availability
Quick Specs
- 32" high to fit under lower ADA compliant counters
- Full 4.1 cu.ft. capacity inside conveniently slim footprint
- Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup
- Turn the light on and off with a convenient rocker switch
- Easy to clean, with more depth for storage
- Pair with FS407LBIMEDADA for a complete ADA compliant undercounter set
- Allows the unit to be used freestanding
- Environmentally friendly design with no ozone-damaging chemicals
- Make the best use of space by installing your appliance under the counter
- Keyed security on the refrigerator door
- Warns of temperature fluctuations and includes an external temperature readout on the door
- Alarm includes continuous NIST calibrated display of the current interior and high/low temperature, and can be switched from Celsius to Fahrenheit at the touch of a button
- Electronic controls (located inside the refrigerator) ensure easy and intuitive temperature management
- Secure three-pronged cord for added unit safety
- Reduced maintenance with auto defrost system
- Fan-forced cooling ensures the unit is evenly cooled from top to bottom
Accucold by Summit Appliance offers the MED Series all-refrigerators, a complete line that comes fully featured for stabilized temperature performance for use in medical, scientific, pharmaceutical, and laboratory institutions. The FF511LBIMEDADA is a 20" wide all-refrigerator designed for built-in use under lower ADA compliant counters. It uses automatic defrost operation complete with an internal fan for even cold air distribution throughout the 4.1 cu.ft. interior. Inside, a digital thermostat allows easy and intuitive temperature management. The door includes a front lock and NIST calibrated high temperature warning alarm that also displays the current and high/low temperatures. Additional features include an interior light, adjustable shelves, and hospital grade cord with a 'green dot' plug for added safety in high traffic areas. The FF511LBIMEDADA can be used built-in or freestanding and paired with the matching FS407LBIMEDADA all-freezer. *NOTE: This unit's thermostat is pre-set for Celsius. If you prefer Fahrenheit, add complimentary option DTMEDF or let your sales representative know upon order.
| Overview | |
| Height of Cabinet | 32.0" (81 cm) |
| Height to Hinge Cap | 32.5" (83 cm) |
| Width | 19.25" (49 cm) |
| Depth | 22.25" (57 cm) |
| Depth with Handle | 23.0" (58 cm) |
| Depth with door at 90° | 39.5" (100 cm) |
| Capacity | 4.1 cu.ft. (116 L) |
| Defrost Type | Automatic |
| Door | White |
| Cabinet | White |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.4 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 64.0 lbs. (29 kg) |
| Shipping Weight | 67.0 lbs. (30 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101035451 |
| Refrigerator Features | |
| Door Swing | RHD |
| Reversible | Factory Reversible |
| Shelf Type | Wire |
| Shelf Qty | 3 |
| Adjustable Shelves | Yes |
| Thermostat Type | Digital |
| Fan Type | Interior |
| Refrigerant Type | R134a |
| Refrigerant Amount | 1.75oz. |
| High Side PSI | 205.0 |
| Low Side PSI | 103.0 |
| Level Legs Qty | 2 |
| Interior Light | Yes |
| Dimensions | |
| Interior Height | 28.5" (72 cm) |
| Interior Width | 15.75" (40 cm) |
| Interior Depth | 18.0" (46 cm) |
| Compressor Step Height | 8.0" (20 cm) |
| Compressor Step Width | 17.0" (43 cm) |
| Compressor Step Depth | 6.75" (17 cm) |
