24" Wide Built-in Refrigerator-freezer, ADA Compliant
Model: CT66LBIPLUS2ADA
24" Wide Built-in Refrigerator-freezer, ADA Compliant
Model: CT66LBIPLUS2ADAQuick Specs
24" Wide Built-in Refrigerator-freezer, ADA Compliant is backordered and will ship as soon as it is back in stock.
SERVICES AVAILABLE
Couldn't load pickup availability
Quick Specs
- 32" high to fit under lower ADA compliant counters
- Make the best use of space by installing your appliance under the counter
- Manage the temperature with ease and accuracy
- Quality door gaskets ensure a tight seal for energy savings and improved performance
- Designed to ensure a sufficiently insulated interior
- ETL and ETL-C listed for North American sales
- Allows the unit to be used freestanding
- Standard unit ships with a right hand door swing. For a left hand door swing, add option LHD upon order (due to its construction, this door is not reversible in the field)
- Environmentally friendly design with no ozone-damaging chemicals
- Keyed lock for secure interior
- Thermometer provides continuous display of the current and high/low temperature to the nearest tenth of a degree, with a readout switchable from Celsius to Fahrenheit at the touch of a button
- Thermometer probe is encased in a glycol-filled bottle to better simulate the temperature of stored contents instead of refrigerator air temperature
- This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment
- Fan-forced cooling helps to ensure more even cooling inside the refrigerator compartment
- Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators
- Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup
- Store items right on the door for easy access
Made in Europe, the CT66LBIPLUS2ADA is a 24" wide and 32" high refrigerator-freezer designed for built-in installation under lower ADA compliant counters. It comes in a white exterior finish, with a factory-installed lock located towards the top of the door for convenient security. The door includes a factory-installed lock and a thermometer calibrated to NIST standards in our ISO/IEC 17025:2005 laboratory. It displays the current, minimum, and maximum temperature to the nearest tenth degree viewable in Celsius or Fahrenheit. The buffered temperature probe is stored in a glycol-filled bottle to ensure the temperature reading best reflects the temperature of other stored refrigerator contents. Inside, this unit utilizes a unique dual evaporator cooling system, with cycle defrost operation for an auto defrost refrigerator section and manual defrost compact freezer compartment. The refrigerator section includes an internal fan for more even cooling, with adjustable wire shelves and door racks for versatile storage. The CT66LBIPLUS2 can be customized with a variety of options, including USB data loggers and self-closing doors, and much more. Contact our sales team for more details. Accucold's PLUS2 series refrigerators are intended for a wide variety of basic storage only. Storage of high-value vaccines, life science materials, medical, or clinical biologicals require a product with design features including, but not limited to tighter temperature controls, monitoring, and/or back-up.
| Overview | |
| Height of Cabinet | 32.0" (81 cm) |
| Height to Hinge Cap | 32.38" (82 cm) |
| Width | 23.63" (60 cm) |
| Depth | 23.5" (60 cm) |
| Depth with Handle | 24.63" (63 cm) |
| Depth with door at 90° | 45.75" (116 cm) |
| Capacity | 5.1 cu.ft. (144 L) |
| Defrost Type | Cycle |
| Door | White |
| Cabinet | White |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.3 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 100.0 lbs. (45 kg) |
| Shipping Weight | 105.0 lbs. (48 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101057484 |
| Refrigerator-Freezer | |
| Door Swing | RHD |
| Reversible | Factory Reversible |
| Adjustable Shelves | Yes |
| Interior Light | Yes |
| Refrigerator - Interior Height | 19.5" (50 cm) |
| Refrigerator - Interior Width | 20.5" (52 cm) |
| Refrigerator - Interior Depth | 17.0" (43 cm) |
| Refrigerator - Shelf Type | Wire |
| Refrigerator - Shelf Qty | 2 |
| Refrigerator - Full Door Shelves | 3 |
| Freezer - Interior Height | 5.0" (13 cm) |
| Freezer - Interior Width | 19.0" (48 cm) |
| Freezer - Interior Depth | 11.5" (29 cm) |
| Thermostat Type | Dial |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R134a |
| High Side PSI | 285.0 |
| Low Side PSI | 70.0 |
| Compressor Step Height | 7.0" (18 cm) |
| Compressor Step Width | 20.5" (52 cm) |
| Compressor Step Depth | 5.0" (13 cm) |
