Built-in Undercounter Frost-free All-freezer for General Purpose Use, With White Exterior, Digital Thermostat, Alarm, Lock, and Hospital Grade Cord
Model: ACF48WMEDDT
Built-in Undercounter Frost-free All-freezer for General Purpose Use, With White Exterior, Digital Thermostat, Alarm, Lock, and Hospital Grade Cord
Model: ACF48WMEDDTQuick Specs
Built-in Undercounter Frost-free All-freezer for General Purpose Use, With White Exterior, Digital Thermostat, Alarm, Lock, and Hospital Grade Cord is backordered and will ship as soon as it is back in stock.
SERVICES AVAILABLE
Couldn't load pickup availability
Quick Specs
- Built-in capable: Front-breathing system allows the unit to be used built-in
- Frost-free operation: Low maintenance design ensures no frost buildup inside the unit
- Flat door liner: Interior design conforms to CDC guidelines to ensure stable conditions for sensitive materials
- Matching refrigerator available: Pair with FF7LBIMEDDT for a complete undercounter set
- Foamed-in-place cabinet: Quality design ensures efficiently insulated interior
- Fully finished white cabinet: Allows the unit to be used freestanding
- 100% CFC Free: Environmentally friendly design with no ozone-damaging chemicals
- Digital thermostat: Electronic controls for more precise temperature management, with temperature readout and controls externally located for added convenience
- High/low temperature alarm: Audible alarm sounds if the interior temperature rises or falls out of set range
- NIST calibrated temperature display: Alarm includes NIST calibrated display of the current interior and high/low temperature
- Internal fan: Fan-forced cooling ensures the unit is evenly cooled from top to bottom
- Factory installed lock: Keyed lock for secure interior
- Hospital grade cord with 'green dot' plug: Secure three-pronged cord for added unit safety
- Removable shelves: Includes two slide-out shelves made from durable steel
- Access port: Unit comes with a factory installed probe hole for users to connect their own monitoring equipment
(UL)(LI)Frost-free operation ensures low maintenance use(/LI)(LI)Flexible design allows built-in or freestanding use in 24 wide spaces(/LI)(LI)Digital thermostat allows more precision in temperature control(/LI)(LI)High temperature alarm includes NIST calibrated external temperature readout(/LI)(LI)Factory installed lock provides security you can count on(/LI)(LI)Includes a hospital grade cord with a 'green dot' plug(/LI)(LI)Made in the U.S.A.(/LI)(/UL)(BR)Accucold by Summit Appliance introduces MEDDT Series all-freezers for improved temperature stability and management and medical, laboratory, and general purpose applications. At 24" wide, the ACF48WMEDDT is ideally sized for virtually any institutional or laboratory setting. The front-breathing design allows built-in installation, while the fully finished cabinet also allows freestanding use. The door includes a factory installed keyed lock for added security and an audible NIST calibrated temperature alarm complete with an external display of the current and high/low temperature mounted on the door. This model comes in a white finish and includes a hospital grade cord with a 'green dot' plug for added security in high traffic areas. An access port allows users to connect their own monitoring equipment. Full frost-free operation eliminates the need to defrost the interior, with an internal fan to keep the interior evenly cooled from top to bottom. A digital thermostat is located in the front kickplate, letting users manage the temperature without having to open the door. The interior includes two removable steel shelves. Made in the USA, the ACF48WMEDDT offers quality freezer storage in a conveniently sized and featured unit. For this unit sized for use under ADA compliant counters, see the ACF48WMEDDTADA. Additional door finishes are available. This model can also be paired with the matching FF7LBIMEDDT all-refrigerator.
| Overview | |
| Height of Cabinet | 33.0" (84 cm) |
| Height to Hinge Cap | 33.5" (85 cm) |
| Width | 23.63" (60 cm) |
| Depth | 23.5" (60 cm) |
| Depth with Handle | 25.13" (64 cm) |
| Depth with door at 90° | 46.13" (117 cm) |
| Capacity | 3.1 cu.ft. (88 L) |
| Defrost Type | Frost-Free |
| Door | White |
| Cabinet | White |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.5 |
| Weight | 110.0 lbs. (50 kg) |
| Shipping Weight | 120.0 lbs. (54 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| Freezer | |
| Door Swing | RHD |
| Reversible | Factory Reversible |
| Shelf Type | Steel |
| Shelf Qty | 2 |
| Thermostat Type | Digital |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R134a |
| Refrigerant Amount | 4.2 oz. |
| High Side PSI | 285.0 |
| Low Side PSI | 70.0 |
| Level Legs | 4 |
| Temperature Range | -5 to 10 F/-20 to -12 C |
| Exterior | |
| SSK - Stainless steel kickplate factory installed | DL1 Temperature Logger - USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac |
| Latch - Top-mounted door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles. | SCD Self-Closing Door - Protect interior contents and reduce energy waste with the Self Closing Door Option |
| ODA Open Door Alarm - Add an open door alarm to audibly buzz when the door is left ajar. | LHD - Door reversal to left hand swing |
| Legs - 6" high leveling legs | HUM Humidity Sensor - Humidity sensor with min/max readout |
| DL2 Temperature Logger - USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout | CAS6 6" casters - 6" high NSF listed casters |
| Agion Door - Treat the door with Agion silver antimicrobial coating to reduce the growth of bacteria, fungi, molds, and other destructive microbes on appliance surface | Agion Cabinet - Exterior cabinet and door treated with Agion silver antimcrobial coating to reduce the growth of bacteria, fungi, molds, and other destructive microbes on appliance surface |
| Lock | |
| KEYPAD - Battery-powered keypad lock installed for keyless security | KEY - Extra keys available for purchase |
| AC Keypad | Keypad lock powered by appliance power cord for keyless security |
- Built-in capable: Front-breathing system allows the unit to be used built-in
- Frost-free operation: Low maintenance design ensures no frost buildup inside the unit
- Flat door liner: Interior design conforms to CDC guidelines to ensure stable conditions for sensitive materials
- Matching refrigerator available: Pair with FF7LBIMEDDT for a complete undercounter set
- Foamed-in-place cabinet: Quality design ensures efficiently insulated interior
- Fully finished white cabinet: Allows the unit to be used freestanding
- 100% CFC Free: Environmentally friendly design with no ozone-damaging chemicals
- Digital thermostat: Electronic controls for more precise temperature management, with temperature readout and controls externally located for added convenience
- High/low temperature alarm: Audible alarm sounds if the interior temperature rises or falls out of set range
- NIST calibrated temperature display: Alarm includes NIST calibrated display of the current interior and high/low temperature
- Internal fan: Fan-forced cooling ensures the unit is evenly cooled from top to bottom
- Factory installed lock: Keyed lock for secure interior
- Hospital grade cord with 'green dot' plug: Secure three-pronged cord for added unit safety
- Removable shelves: Includes two slide-out shelves made from durable steel
- Access port: Unit comes with a factory installed probe hole for users to connect their own monitoring equipment
