Undercounter Refrigerator 24", Pull Out Door/Drawer
Model UPR513
Authorized Dealer
1
of
9
Loading...
Authorized Dealer
Undercounter Refrigerator 24", Pull Out Door/Drawer
Model UPR513Quick Specs
Depth
21.688
Height
34.688
Sabbath
YES
Fresh
4.8
Cu Ft
4.8
Size
4.8
Shelves
3
ADA
NO
Undercounter Refrigerator 24", Pull Out Door/Drawer is backordered and will ship as soon as it is back in stock.
This item qualifies for free delivery
Ships Out Within: 2 - 4 Business Days
Shipping Date By: 06/29/2026
Regular price
$1,413.65
Unit price
/
Unavailable
SERVICES AVAILABLE
Selection will add
$0.00
to the price
Couldn't load pickup availability
Quick Specs
Depth
21.688
Height
34.688
Sabbath Mode
YES
Fresh food Capacity
4.8
Capacity (cu ft.)
4.8
Refrigerator Size
4.8
Refrigerator number of Shelves
3
ADA
NO
Dispenser
NO
Icemaker
NO
Wifi Connected
NO
Counter Depth
NO
RPM
-1.0
Energy Star Rated
YES
German engineering
(P)Our superior products offer premium quality, cutting edge design and innovative features that fit with your busy lifestyle. Plus, exclusive components and materials along with the latest production processes ensure energy efficiency and performance for years to come.(/P)
Energy Star
(P)Liebherr refrigerators help to produce less energy waste and greenhouse gas emissions with the aim of having the least damaging effect on the environment and offering solutions that help consumers conserve energy.(/P)
SuperCool
(P)The automatic SuperCool function lowers the refrigerator temperature down to as far as 36 F for as long as 12 hours - ideal for rapidly cooling freshly stored food.(/P)
Door alarm
(P)The audible door alarm alerts the user if the door has been open for longer than 60 seconds for safe protection of the food.(/P)
VarioBase
(P)The VarioBase permits the adjustment of kitchen units in height and depth. All four height-adjustable feet permit adjustment from the front with a 2.5 in. range. In addition, the ventilation grille can be adjusted within a range of 2 in. to match the front of the kitchen units.(/P)
LiftUp-Box
(P)The LiftUp-Box allows you to fully utilize the storage space below the pull-out drawer. It is ergonomically attached, easy to take out and can hold up to 9 lbs. When pulled out, the LiftUp-Box pushes up out of the base recess, allowing the food to be removed easily. (/P)- Net Total Capacity: 4.40 ft
- Defrost Type: Auto-defrost
- Net Refrigerator Capacity: 4.40 ft
- Input Voltage: 120 V AC
- Energy Consumption per Year: 225 kWh
- Climate Class: SN-T
- Installation Type: Built-under
- Height: 32.3"
- Width: 34.7"
- Depth: 23.6"
- Weight (Approximate): 96.30 lb
- Number of Doors/Drawers: 2
- Lighting Type: LED
- Style: Undercounter
- Features: Temperature Display
- Features: Super Cooling
- Features: Quiet Operation
- Features: Bottle Storage
- Features: Egg Storage
| General product information | |
| Model type | Fully Integrated undercounter Refrigerator |
| GTIN | 4016803122579 |
| Series | Premium |
| Output and consumption | |
| Energy consumption per year | 205 kWh/a |
| Noise level | 37 dB |
| Energy Label | EnergyStar |
| Energy consumption in 24h | 0.561 kWh / 24h |
| Voltage | 115 V ~ |
| Frequency | 60 Hz |
| Connection rating | 2.3 A |
| Control and functions | |
| Type of control | Magic Eye with LC and digital temperature display |
| Position of control unit | behind the door |
| Control unit | Touch |
| Number of temperature zones | 1 |
| Number of regulated refrigeration circuits | 1 |
| Temperature display | Fridge compartment |
| Front frame heater | present |
| SuperCool | Yes |
| Door alarm, cooling | visual and audible |
| BottleTimer | - |
| Refrigerator compartment | |
| Adjustable temperature range | +34 °F to +46 °F |
| Defrosting method | automatic |
| SoftSystem | SoftSystem |
| Interior light, fridge compartment | LED light |
| Number of storage shelves, refrigerator compartment | 2 |
| Of which separable | 0 |
| of which height-adjustable | 0 |
| Bottle rack | 0 |
| Number of can racks | 0 |
| VarioBox | - |
| VarioBoxes | 0 |
| Butter dish | Yes |
| Egg tray | Variable |
| Storage rack | - |
| Pull-out unit | Yes |
| LiftUp Box: | Yes |
| Design and materials | |
| Material door bins | - |
| Storage shelf material, fridge compartment | Glass |
| Cabinet Material | Door prepared for stainless steel panel |
| Set-up and installation | |
| Type of installation | Undercounter |
| door assembly | Pull-out drawer |
| Door hinges | Pull-out |
| Door opening angle | - |
| Height-adjustable feet | 4 |
| Leveling bars | - |
| Ventilation | Base ventilation |
| Plug type | USA |
| Connector cable (length) | 2,220 mm |
| Specifications | |
| Net capacity, total | 4.4 cubic feet |
| Niche Height | 0 inch |
| Range of appliance width | 24 inch |
| Min. depth | 22 inch |
| Exterior dimensions: height/width/depth | 32 5/16 23 9/16 21 11/16 inch |
| Exterior dimensions: height/width/depth (with packaging) | 36 1/2 24 1/4 24 5/16 inch |
| Weight (without packaging) | 97.9 pounds |
| Weight (with packaging) | 111.6 pounds |
- Net Total Capacity: 4.40 ft
- Defrost Type: Auto-defrost
- Net Refrigerator Capacity: 4.40 ft
- Input Voltage: 120 V AC
- Energy Consumption per Year: 225 kWh
- Climate Class: SN-T
- Installation Type: Built-under
- Height: 32.3"
- Width: 34.7"
- Depth: 23.6"
- Weight (Approximate): 96.30 lb
- Number of Doors/Drawers: 2
- Lighting Type: LED
- Style: Undercounter
- Features: Temperature Display
- Features: Super Cooling
- Features: Quiet Operation
- Features: Bottle Storage
- Features: Egg Storage
VarioBase
VarioBase (P)The VarioBase permits the adjustment of kitchen units in height and depth. All four height-adjustable feet permit adjustment from the front with a 2.5 in. range. In addition, the ventilation grille can be adjusted within a range of 2 in. to match the front of the kitchen units.(/P)
SuperCool
SuperCool (P)The automatic SuperCool function lowers the refrigerator temperature down to as far as 36(degree)F for as long as 12 hours - ideal for rapidly cooling freshly stored food.(/P)
Energy Star
Energy Star (P)Liebherr refrigerators help to produce less energy waste and greenhouse gas emissions with the aim of having the least damaging effect on the environment and offering solutions that help consumers conserve energy.(/P)
LiftUp-Box
LiftUp-Box (P)The LiftUp-Box allows you to fully utilize the storage space below the pull-out drawer. It is ergonomically attached, easy to take out and can hold up to 9 lbs. When pulled out, the LiftUp-Box pushes up out of the base recess, allowing the food to be removed easily. (/P)
Door alarm
Door alarm (P)The audible door alarm alerts the user if the door has been open for longer than 60 seconds for safe protection of the food.(/P)
German engineering
German engineering (P)Our superior products offer premium quality, cutting edge design and innovative features that fit with your busy lifestyle. Plus, exclusive components and materials along with the latest production processes ensure energy efficiency and performance for years to come.(/P)
- German engineering
German engineering
(P)Our superior products offer premium quality, cutting edge design and innovative features that fit with your busy lifestyle. Plus, exclusive components and materials along with the latest production processes ensure energy efficiency and performance for years to come.(/P)Energy Star
(P)Liebherr refrigerators help to produce less energy waste and greenhouse gas emissions with the aim of having the least damaging effect on the environment and offering solutions that help consumers conserve energy.(/P)SuperCool
(P)The automatic SuperCool function lowers the refrigerator temperature down to as far as 36 F for as long as 12 hours - ideal for rapidly cooling freshly stored food.(/P)Door alarm
(P)The audible door alarm alerts the user if the door has been open for longer than 60 seconds for safe protection of the food.(/P)VarioBase
(P)The VarioBase permits the adjustment of kitchen units in height and depth. All four height-adjustable feet permit adjustment from the front with a 2.5 in. range. In addition, the ventilation grille can be adjusted within a range of 2 in. to match the front of the kitchen units.(/P)LiftUp-Box
(P)The LiftUp-Box allows you to fully utilize the storage space below the pull-out drawer. It is ergonomically attached, easy to take out and can hold up to 9 lbs. When pulled out, the LiftUp-Box pushes up out of the base recess, allowing the food to be removed easily. (/P)- Net Total Capacity: 4.40 ft
- Defrost Type: Auto-defrost
- Net Refrigerator Capacity: 4.40 ft
- Input Voltage: 120 V AC
- Energy Consumption per Year: 225 kWh
- Climate Class: SN-T
- Installation Type: Built-under
- Height: 32.3"
- Width: 34.7"
- Depth: 23.6"
- Weight (Approximate): 96.30 lb
- Number of Doors/Drawers: 2
- Lighting Type: LED
- Style: Undercounter
- Features: Temperature Display
- Features: Super Cooling
- Features: Quiet Operation
- Features: Bottle Storage
- Features: Egg Storage
| General product information | |
| Model type | Fully Integrated undercounter Refrigerator |
| GTIN | 4016803122579 |
| Series | Premium |
| Output and consumption | |
| Energy consumption per year | 205 kWh/a |
| Noise level | 37 dB |
| Energy Label | EnergyStar |
| Energy consumption in 24h | 0.561 kWh / 24h |
| Voltage | 115 V ~ |
| Frequency | 60 Hz |
| Connection rating | 2.3 A |
| Control and functions | |
| Type of control | Magic Eye with LC and digital temperature display |
| Position of control unit | behind the door |
| Control unit | Touch |
| Number of temperature zones | 1 |
| Number of regulated refrigeration circuits | 1 |
| Temperature display | Fridge compartment |
| Front frame heater | present |
| SuperCool | Yes |
| Door alarm, cooling | visual and audible |
| BottleTimer | - |
| Refrigerator compartment | |
| Adjustable temperature range | +34 °F to +46 °F |
| Defrosting method | automatic |
| SoftSystem | SoftSystem |
| Interior light, fridge compartment | LED light |
| Number of storage shelves, refrigerator compartment | 2 |
| Of which separable | 0 |
| of which height-adjustable | 0 |
| Bottle rack | 0 |
| Number of can racks | 0 |
| VarioBox | - |
| VarioBoxes | 0 |
| Butter dish | Yes |
| Egg tray | Variable |
| Storage rack | - |
| Pull-out unit | Yes |
| LiftUp Box: | Yes |
| Design and materials | |
| Material door bins | - |
| Storage shelf material, fridge compartment | Glass |
| Cabinet Material | Door prepared for stainless steel panel |
| Set-up and installation | |
| Type of installation | Undercounter |
| door assembly | Pull-out drawer |
| Door hinges | Pull-out |
| Door opening angle | - |
| Height-adjustable feet | 4 |
| Leveling bars | - |
| Ventilation | Base ventilation |
| Plug type | USA |
| Connector cable (length) | 2,220 mm |
| Specifications | |
| Net capacity, total | 4.4 cubic feet |
| Niche Height | 0 inch |
| Range of appliance width | 24 inch |
| Min. depth | 22 inch |
| Exterior dimensions: height/width/depth | 32 5/16 23 9/16 21 11/16 inch |
| Exterior dimensions: height/width/depth (with packaging) | 36 1/2 24 1/4 24 5/16 inch |
| Weight (without packaging) | 97.9 pounds |
| Weight (with packaging) | 111.6 pounds |
- Net Total Capacity: 4.40 ft
- Defrost Type: Auto-defrost
- Net Refrigerator Capacity: 4.40 ft
- Input Voltage: 120 V AC
- Energy Consumption per Year: 225 kWh
- Climate Class: SN-T
- Installation Type: Built-under
- Height: 32.3"
- Width: 34.7"
- Depth: 23.6"
- Weight (Approximate): 96.30 lb
- Number of Doors/Drawers: 2
- Lighting Type: LED
- Style: Undercounter
- Features: Temperature Display
- Features: Super Cooling
- Features: Quiet Operation
- Features: Bottle Storage
- Features: Egg Storage
