48" Custom Hood Insert
Model: UVC9480SLSS
48" Custom Hood Insert
Model: UVC9480SLSSQuick Specs
48" Custom Hood Insert is backordered and will ship as soon as it is back in stock.
SERVICES AVAILABLE
Couldn't load pickup availability
Quick Specs
Heat Sensor
This temperature sensor range hood will automatically turn on if the heat sensor detects high temperatures, preventing damage by reducing heat
LED Hood Light
Get a bright view of your cooktop as you prepare your favorite meals with LED lighting in this range hood
- LED Hood Light
- Get a bright view of your cooktop as you prepare your favorite meals with LED lighting in this range hood
- 1200 CFM Range Hood Blower Motor
- This high-CFM range hood offers powerful ventilation that keeps your kitchen fresh and free of cooking fumes and odors
- Built-In WiFi
- This smart range hood lets you adjust vent speed and turn on lights using your phone, for the ultimate in kitchen convenience
- ADA Compliant
- This ADA compliant range hood can be operated with a mobile device, eliminating reaching and improving safety for users of all abilities
- Baffle Filters
- The baffle filters in this range hood trap more grease and require less frequent cleaning than standard filters
- Chef Connect
- Synchronize your oven and GE Appliances hood insert so the hood turns on when the cooktop turns on and the lights illuminate when a burner is activated
- Backlit Push Button Controls
- Easily operate this range hood with push buttons that are illuminated from behind and simple to find and reach
- 4-Speed Fan
- Have strong ventilation at four fan speeds that you can adjust to match your cooking techniques
- Night Light Setting
- Turn on the range hood night light setting for a soft glow in the kitchen at night
- Heat Sensor
- This temperature sensor range hood will automatically turn on if the heat sensor detects high temperatures, preventing damage by reducing heat
- Customizable Fit
- The included side panels are designed to seamlessly attach to the hood insert, allowing it to perfectly fit into a 45" cutout.
- Remote control included
- Activate and adjust your hood functions from anywhere in the kitchen
- LED Hood Light
- 1200 CFM Range Hood Blower Motor
- Customizable Fit
- Remote control included
- Built-In WiFi
- ADA Compliant
- Baffle Filters
- Chef Connect
- Backlit Push Button Controls
- 4-Speed Fan
- Night Light Setting
- Heat Sensor
| FILTER | |
| App Filter-Multi Brand | Cafe GE Monogram |
| App Filter - Hood Type | Custom Hood Insert |
| App Filter - Venting Type | Convertible |
| APPEARANCE | |
| Custom Insert | Yes |
| Material | Steel |
| Design Style | Custom |
| Color Appearance | Stainless Steel |
| POWER / RATINGS | |
| Watts | 470 |
| Hertz | 60 |
| Electrical Requirements | 120V ; 60Hz ; 6.0A |
| Amp Rating at 120V | 6.0 |
| WARRANTY | |
| Labor Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
| Parts Warranty | Limited 1-year entire appliance |
| ECONOMICAL / QUIET | |
| Venting Type | Externally Vented |
| ACCESSORIES | |
| Optional Accessories | JXHC1 - Power Cord Kit |
| WEIGHTS & DIMENSIONS | |
| Cabinet Width | 48 in |
| Overall Width with side panels installed | 46 5/16 in |
| Net Weight | 97 lb |
| Overall Depth | 21.875 in |
| Approximate Shipping Weight | 121 lb |
| Overall Height | 12.5 in |
| Overall Width | 39.625 in |
| FEATURES | |
| WiFi Connect | Built-In |
| Cooktop Lighting | 4 LED |
| Max CFM | 780 |
| Required Duct Size | 10" Round |
| CFM/ Sones Rating | 780/7.0 (Boost speed) - Vertical venting |
| Time Delay Shut-Off | Yes |
| Exhaust Options | 10" Round Duct Vertical |
| Lighting | LED On/Off/Night Light |
| Product Type | Custom Hood Insert |
| Control Features | Delay Off Fan Speed (+) (-) Fan Speed Boost Heat Sensor Light Off/On/Night Light Power On/Off Time to clean filter warning (in app feature) |
| Vertical Exhaust Blower Rating (CFM) | 1220 |
| Remote Control | Included |
| Variable Speed Fan | Yes |
| Sones Rating : Top Exhaust-Round | 10.0 |
| Control Type | Backlit Pushbutton |
| Baffle Stainless Steel Filters | 4 |
| Connected Capabilities | Amazon Alexa Google Home |
| Dual Blowers | Yes |
| Collection | Minimalist Statement |
| Removable Filter | Yes |
| Charcoal Filter | Yes |
| Recirculating Capable | No |
| Blower Levels | 4 Including Boost |
