Gas Range, 30", 5 Burners
Model: RGV2305NN
Gas Range, 30", 5 Burners
Model: RGV2305NNQuick Specs
Gas Range, 30", 5 Burners is backordered and will ship as soon as it is back in stock.
SERVICES AVAILABLE
Couldn't load pickup availability
Quick Specs
Cooktop power
BEAUTIFUL TO USE Cooktop power Sealed Dual Flow Burners? deliver cooktop power up to 23,500 BTU (NG models) for seriously fast boiling right down to a precise 140 F full surface simmer with the gentlest of flames.
Cooking flexibility
BEAUTIFUL TO USE Cooking flexibility The cooktop is designed for easy access to any burner, with grates you can smoothly slide pots across, while the oven cavity is large enough to allow you to cook multiple dishes at once
Easy to clean
BEAUTIFUL TO USE Easy to clean A sealed cooktop surface coupled with a commercial-style stainless steel finish means your cooktop simply needs a quick wipe to keep it looking good as new.
Total control
PERFECT RESULTS Total control Precise control across high and low settings is delivered through the halo-illuminated cooktop dials. The ovens have true convection and electronic oven control for precise and consistent temperatures.
Design quality
DESIGNED TO FIT Design quality This range has been carefully crafted in every detail from performance to durability using quality materials.
Instant visibility
BEAUTIFUL TO USE Instant visibility Control dials have halo-illumination glowing white ? heating up; orange ? temperature reached; red ? self-cleaning mode. The oven is illuminated by two powerful incandescent lights.
- Cooktop power
- Sealed Dual Flow Burners? deliver cooktop power up to 23,500 BTU (NG models) for seriously fast boiling right down to a precise 140 F full surface simmer with the gentlest of flames.
- Total control
- Precise control across high and low settings is delivered through the halo-illuminated cooktop dials. The ovens have true convection and electronic oven control for precise and consistent temperatures.
- Easy to clean
- A sealed cooktop surface coupled with a commercial-style stainless steel finish means your cooktop simply needs a quick wipe to keep it looking good as new.
- Instant visibility
- Control dials have halo-illumination glowing white ? heating up; orange ? temperature reached; red ? self-cleaning mode. The oven is illuminated by two powerful incandescent lights.
- Cooking flexibility
- The cooktop is designed for easy access to any burner, with grates you can smoothly slide pots across, while the oven cavity is large enough to allow you to cook multiple dishes at once
- Design quality
- This range has been carefully crafted in every detail from performance to durability using quality materials.
- Top burner heat of 23,500 BTU, for seriously fast boiling
- Gas oven with 4.6 cu ft total capacity
- Non-tip full-extension shelves for safe removal of hot dishes
| Accessories | |
| Square handle option | AH-R30 |
| Controls | |
| Metal illuminated dials | Yes |
| Gas requirements | |
| Fitting and pipe | 1/2 NPT, min. ⅝" flex line |
| Main oven features | |
| Broil pan | Yes |
| Capacity total (AHAM) | 4.6cu ft |
| Capacity usable (AHAM) | 3.4cu ft |
| Electronic oven control | Yes |
| Infrared Broiler | Yes |
| Internal Light | Yes |
| Shelf positions | 5 |
| Main oven functions | |
| Bake | 28000BTU |
| Broil | 19000BTU |
| Number of main oven functions | 3 |
| Oven features | |
| Full extension telescopic sliding shelves | 3 |
| Power requirements | |
| Supply frequency | 60 |
| Supply voltage | 120 |
| Product dimensions | |
| Depth | 29 1 ⁄ 8 " |
| Height | 35 3 ⁄ 4 - 36 3 ⁄ 4 " |
| Width | 29 7 ⁄ 8 " |
| Rangetop features | |
| Sealed Dual Flow Burners™ | 5 |
| Sealed range top | Yes |
| Simmer on all burners | 140°F |
| Vent trim included | Flat vent trim |
| Rangetop Performance | |
| Max burner power | 23500BTU |
| Power back left | 18500BTU |
| Power back right | 18500BTU |
| Power centre | 23500BTU |
| Power front left | 18500BTU |
| Power front right | 18500BTU |
| Total cooktop power | 97500BTU |
| Safety | |
| Full extension telescopic sliding shelves | Yes |
- Top burner heat of 23,500 BTU, for seriously fast boiling
- Gas oven with 4.6 cu ft total capacity
- Non-tip full-extension shelves for safe removal of hot dishes
