Quick Specifications
Quick Specifications
- Type : ELECTRIC RANGES
- Style : COOKTOPS (ELECTRIC)
- Width : 36.06"
- Height : 2.5"
- Depth : 22.18"
- Energy Star Rated : NO
- Wifi Connected : NO
- Downdraft Ventilation : NO
- Sabbath Mode : NO
- Induction : YES
Documents
Documents
Delivery
Delivery
Professional delivery and installation is available for every product we sell. We would be happy to coordinate delivery and installation for you.
Warranty
Warranty
Extended warranties are usually very inexpensive and can save you thousands in the future. Some can even cover extra costs that result, such as cost of food that spoils when your fridge dies. It's simple and inexpensive to purchase extended warranties and one of the smartest ways to protect your investment.
Appliances can be large, heavy and expensive. You probably don't have the special tools or expertise needed to fix them in a crisis. If you can spare a few thousand dollars without batting an eyelash for new appliances should they break tomorrow, don't buy a warranty. But if you're like most of us, protect yourself by purchasing inexpensive extended warranties when you buy a new product and save yourself big money in the long run.
- Delay Switch Off
- A smart timer feature allows you to set the automatic switch-off of the product after a predetermined time. Delayed shutdown may be used in order to leave the hood on even after cooking, so to fully remove stubborn odors and residual humidity.
- Extralarge Zone
- With Extralarge Zone you can cook with large pots and pans (up to 30 cm in diameter), or prepare special dishes faster, thanks to high power levels.
- Melting Mode
- This feature is the ideal for more delicate cooking where high temperatures would spoil the texture or taste. The temperature is kept very low (below 50(degree)) to assure that the ingredients fully melt but without the need to continuously stir them.
- Pot Self-Detection
- The hob is equipped with special technology that automatically detects the presence of cookware on the cooking zones. Once detected, the corresponding controls will light up on the interface, thus letting the user set the power level.
- Total Integration
- Always more popular in today's modern kitchen, "total look" trend enhances homogeneous, uniform and linear design. The products perfectly blend in minimal design kitchens and living rooms, thanks to installation solutions that can adapt to every space, both in cabinets and plasterboard, in total harmony with their surroundings.
- Bridge Zones
- When you cook using large and especially rectangular or oval pans the part not on the heating zones will be cooler. The Bridge Zone function solves the problem by joining two cooking zones into a single larger one.
- Child Lock
- This function is valuable to prevent accidental switching on in the presence of children and when cleaning the hob.
- Temperature Manager
- On a daily basis, we often prepare our own signature recipes as well as standard dishes. The Temperature Manager function is an excellent tool for optimising times. Just start one of the three pre-set programs (42, 72 or 92 degrees) with a simple, intuitive button and start cooking your more delicate dishes, such as mousses or sauces, reheating dishes or boiling water. No wasting of time and maximum efficiency.
- Timer
- Forget about cooking times by turning on the timer. Just set the minutes and start the countdown. At the end, the cooking area will be automatically switched off and a beeper will sound. You can set independent timers on more than one area at the same time.
- Stop&Go
- The Stop&Go feature lets us pause all of the features in use on the hob, to later restore them back to what was previously set, by just pressing a button. Thus combining safety, great cooking results and multitasking magamenent in a single touch.
- Pot Detector
- It is easy to see where to position the pot on the induction hob. With Pot Detector, the hob automatically detects the presence of the pot on the cooking area and provides heat only when it is correctly positioned.
- Timer
- Stop and go
- Delay switch off_x005F_x001F_ Temperature manager
- Bridge zones
- Pot self-detection
- Total integration
- Extralarge zone
- Touch controls
Warranty | 3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com |
SHIPPING WEIGHT (kg) | 25.60 |
NET WEIGHT (kg) | 22.40 |
CARTON LENGHT (mm) | 1433.58 |
CARTON HEIGHT (mm) | 1254.25 |
CARTON DEPTH (mm) | 979.68 |
VOLUMEN (M3) | 188.21 |
SHIPPING WEIGHT | 56.44 |
NET WEIGHT | 49.38 |
CARTON LENGHT | 38.57 |
CARTON HEIGHT | 7.41 |
CARTON DEPTH | 25.50 |
COUNTRY OF MANUFACTURE | MX |
Finish | Black Ceramic Glass |
Color | black |
FEATURES | Timer, Stop and go, Delay switch off_x005F_x001F_ Temperature manager, Bridge zones, Pot self-detection, Total integration, Extralarge zone, Touch controls |
WIDTH (IN) | 36" |
WIDTH (CM) | 90.00 |
AIRFLOW (M3/H) | NA |
CFM (MAX) | NA |
db (min) | NA |
db (max) | NA |
SONES | NA |
GREASE FILTER TYPE | NA |
DISHWASHERSAFE FILTER | YES |
FILTER MATERIAL | NA |
BLOWER TYPE | NA |
EXHAUST SIZE | NA |
CONTROL TYPE | Electronic Glass Touch & Slide w/ Red Illumination |
SPEED CONTROL | NA |
NUMBER OF SPEEDS | NA |
REMOTE CONTROL | NO |
POWER SOURCE | Hardwired |
CFM REDUCTION | NA |
HEATING LEVEL | 9 levels + Boost |
COOKING ZONE | 5.00 |
Burner Style | Induction |
Cooktop Type | Cooktop |
Fuel Type | Induction |
Element Type | Induction |
Ignition Type | Automatic Electronic |
Induction | Yes |
Number Of Burners | 5.00 |
Hot Surface Indicator Lights | YES |
Installation Type | Self Rimming or Flush Installation |
Material | Ceramic Tempered Glass |
Cooktop Surface Style | Glass-Top |
Total BTUs | NA |
Auto Shut Off | Yes |
Child Lock | Yes |
Approved for Commercial Use | No |
Commercial | No |
Continuous Grates | YES |
Downdraft Ventilated | No |
Griddle | No |
Grill | No |
Ignition Type | Electric |
Outdoor Approved | No |
Power Burner | No |
Sabbath Mode | No |
Smart Home | No |
WIFI APPROVED | No |
Fingerprint Resistant Finish | No |
Bridge Element | Yes |
Pan Recognition Sensor | Yes |
Warm Function | Yes |
Wireless Communication | NO |
ELECTRIC (VOLTS) | 220 V/60 Hz |
AMPERAGE | 44.00 |
HERTZ | 65 Hz |
EXHAUST VERSION | NA |
DIMENSIONS | 90 x 56 x 6 |
DIMENSIONS inches | 36 1/16" x 22 3/16" x 2 1/2" |
Depth | 22 3/16" |
Height | 2 1/2" |
Width | 36 1/16" |
Cutout Depth | 20 1/2" |
Cutout Height | 3 5/8" |
Cutout Width | 34 9/16" |
Wattage | 10.50 |
Back Left Burner Watts | 3700.00 |
Back Middle Burner Watts | NA |
Back Right Burner Watts | 2200.00 |
Front Left Burner Watts | 3700.00 |
Front Middle Burner Watts | NA |
Front Right Burner Watts | 3700.00 |
Middle Burner Watts | 3700.00 |
Transition Conversion Fitting | NA |
Recirculating Kits | NA |
Certifications | ADA, UL, cUL. |
ADA | YES |
CEC Approved for CA Sale | YES |
Title 20 Compliant | YES |
Energy Star | NO |
Certificado NOM | Activo |
