30" Series 9 Integrated Refrigerator Freezer
Model RS3084WLUK1
30" Series 9 Integrated Refrigerator Freezer
Model RS3084WLUK1Quick Specs
30" Series 9 Integrated Refrigerator Freezer is backordered and will ship as soon as it is back in stock.
SERVICES AVAILABLE
Couldn't load pickup availability
Quick Specs
Complementary Design
DESIGNED TO FIT Complementary Design Both the 24" and 30" Integrated Refrigerator Freezers can be installed separately or paired with a Column Refrigerator, Freezer or Wine Column. Customize with your own kitchen cabinetry and handles, or purchase our stainless steel door panel and handle options.
Internal Water Dispenser And Ice Maker
BEAUTIFUL TO USE Internal Water Dispenser And Ice Maker Both the water dispenser and ice maker are located inside this Integrated model, leaving an uninterrupted exterior. Internal storage space is maximized thanks to a flush-fit slimline water dispenser that gives a continuous flow of temperature-controlled chilled water to fill almost any size or shape of vessel. The dual valve system instantly stops water flow to prevent drips and spills.
Activesmart(TM) Foodcare
PERFECT RESULTS Activesmart(TM) Foodcare ActiveSmart(TM) Foodcare learns how you live. It's technology which understands how you use your refrigerator and adjusts temperature, airflow and humidity inside to help keep food fresher for longer.
Perfect Fit
DESIGNED TO FIT Perfect Fit These models fit flush and have only 1/8" gaps around them with no visible hinges or grilles. Our Integrated models can be seamlessly hidden behind your cabinetry for an understated and clean look with any kitchen layout.
Flexible Storage
BEAUTIFUL TO USE Flexible Storage Designed to make it simple for you to store, access and remove food, this refrigerator includes LED-lit adjustable cantilevered shelving and full extension bins in the freezer. The door and veggie bins are family safe, allowing for hands-free operation thanks to its soft close mechanism
Design Quality
BUILT TO LAST Design Quality The premium design and finish includes a steel interior lining as well as full extension metal shelf runners for easy access, robust glass shelving and quality hinges designed for daily use.
Variable Temperature Zone
PERFECT RESULTS Variable Temperature Zone Create the perfect climate and store each type of food at optimal temperature and humidity with Variable Temperature Zone, reducing food waste due to spoiling. You have the choice of four food modes: Pantry, Fridge, Soft Freeze or Freezer. Use the Max cold feature for periods of high refrigerator or freezer use, or full grocery loads.
- Variable Temperature Zone
- Create the perfect climate and store each type of food at optimal temperature and humidity with Variable Temperature Zone, reducing food waste due to spoiling. You have the choice of four food modes: Pantry, Fridge, Soft Freeze or Freezer. Use the Max cold feature for periods of high refrigerator or freezer use, or full grocery loads.
- Activesmart™ Foodcare
- ActiveSmart™ Foodcare learns how you live. It's technology which understands how you use your refrigerator and adjusts temperature, airflow and humidity inside to help keep food fresher for longer.
- Internal Water Dispenser And Ice Maker
- Both the water dispenser and ice maker are located inside this Integrated model, leaving an uninterrupted exterior. Internal storage space is maximized thanks to a flush-fit slimline water dispenser that gives a continuous flow of temperature-controlled chilled water to fill almost any size or shape of vessel. The dual valve system instantly stops water flow to prevent drips and spills.
- Flexible Storage
- Designed to make it simple for you to store, access and remove food, this refrigerator includes LED-lit adjustable cantilevered shelving and full extension bins in the freezer. The door and veggie bins are family safe, allowing for hands-free operation thanks to its soft close mechanism
- Complementary Design
- Both the 24" and 30" Integrated Refrigerator Freezers can be installed separately or paired with a Column Refrigerator, Freezer or Wine Column. Customize with your own kitchen cabinetry and handles, or purchase our stainless steel door panel and handle options.
- Perfect Fit
- These models fit flush and have only 1/8" gaps around them with no visible hinges or grilles. Our Integrated models can be seamlessly hidden behind your cabinetry for an understated and clean look with any kitchen layout.
- Design Quality
- The premium design and finish includes a steel interior lining as well as full extension metal shelf runners for easy access, robust glass shelving and quality hinges designed for daily use.
- Keep food fresher for longer by constantly maintaining the ideal temperature with ActiveSmart(TM) technology
- Create the perfect climate for each type of food with Variable Temperature Zone: choice of four food modes, Pantry, Fridge, Soft Freeze or Freezer
- Convenient access to fresh, chilled water and ice with internal water dispenser and ice maker
- Customize with your own kitchen cabinetry or purchase our stainless steel door panel and handle accessories
| Accessories (sold separately) | |
| Door panel stainless steel Left hinge 84" | RD3084WLD |
| Door panel stainless steel Right hinge 84" | RD3084WRD |
| Handle kit Classic | AHCLRD3084W |
| Handle kit Contemporary round, aluminium | AHSRD3084W |
| Handle kit Contemporary square fine, aluminium | AHD5RD3084W |
| Handle kit Contemporary square fine, black | AHD5RD3084WB |
| Handle kit Professional round flush | AHP3RD3084W |
| Handle kit Professional round flush, Brass off-stands | AHP3RD3084WBA |
| Handle kit Professional round flush, Dark Copper off-stands | AHP3RD3084WDC |
| Joiner kit | AJ-RS84LR |
| Toe kick stainless steel 30" | AKRS3004 |
| Toe kick stainless steel 48" | AKRS4804 |
| Toe kick stainless steel 54" | AKRS5404 |
| Toe kick stainless steel 60" | AKRS6004 |
| Toe kick stainless steel 66" | AKRS6604 |
| Toe kick stainless steel 72" | AKRS7204 |
| Toe kick stainless steel 78" | AKRS7804 |
| Toe kick stainless steel 84" | AKRS8404 |
| Water filter replacement | 847200 - FWC3 |
| Capacity | |
| Total gross capacity | 15.87cu ft |
| Volume | 15.9cu ft |
| Volume freezer | 5.4cu ft |
| Volume refrigerator | 10.5cu ft |
| Consumption | |
| Energy rating | Energy star |
| Energy usage | 478kWh/year |
| Features | |
| Adjustable door shelves | 4 |
| Covered door shelves | 1 |
| Fruit and vegetable bins | 2 |
| Gallon door shelves | 1 |
| Stackable bottle holders | 4 |
| Freezer Features | |
| Freezer bins | 2 |
| Freezer trays | 1 |
| Performance | |
| Variable food modes | Pantry; Fridge; Soft freeze; Freezer |
| Variable temperature zones | 2 |
| Power requirements | |
| Rated current | 10A |
| Supply frequency | 60Hz |
| Supply voltage | 115V |
| Product dimensions | |
| Depth | 24 " |
| Height | 84 " |
| Width | 29 3 / 4 " |
| Product information | |
| Packaged weight | 406lbs |
| Unpackaged weight | 304lbs |
- Keep food fresher for longer by constantly maintaining the ideal temperature with ActiveSmart(TM) technology
- Create the perfect climate for each type of food with Variable Temperature Zone: choice of four food modes, Pantry, Fridge, Soft Freeze or Freezer
- Convenient access to fresh, chilled water and ice with internal water dispenser and ice maker
- Customize with your own kitchen cabinetry or purchase our stainless steel door panel and handle accessories
