30" Series 9 Professional Duel Fuel 4 Burner Range
Model RDV2304NN
30" Series 9 Professional Duel Fuel 4 Burner Range
Model RDV2304NNQuick Specs
30" Series 9 Professional Duel Fuel 4 Burner Range is backordered and will ship as soon as it is back in stock.
SERVICES AVAILABLE
Couldn't load pickup availability
Quick Specs
Instant Visibility
Control dials have halo-illumination glowing white - heating up; orange - temperature reached; red - self-cleaning mode. The oven is illuminated by two powerful incandescent lights.
Consistent Broiling
The Dual Fuel Range broiler provides an even heat that covers a very large surface area - perfect for browning a fully loaded oven tray.
Total Control
Precise control across high and low settings is delivered through the halo-illuminated cooktop dials. The ovens have true convection and electronic oven control for precise and consistent temperatures.
Cooking Flexibility
BEAUTIFUL TO USE Cooking Flexibility The cooktop is designed for easy access to any burner, with grates you can smoothly slide pots across, while the oven cavity is large enough to allow you to cook multiple dishes at once.
Easy To Clean
The Dual Fuel Range oven has a self-cleaning function and removable side racks. The cooktop has sealed burners and an encapsulated cooking surface with a commercial-style stainless steel finish.
Cooktop Power
BEAUTIFUL TO USE Cooktop Power Sealed Dual Flow Burners(TM) deliver cooktop power up to 22,500 BTU (NG models) for seriously fast boiling right down to a precise 140(degree)F full surface simmer with the gentlest of flames.
- Cooktop Power
- Sealed Dual Flow Burners™ deliver cooktop power up to 22,500 BTU (NG models) for seriously fast boiling right down to a precise 140(degree)F full surface simmer with the gentlest of flames.
- Total Control
- Precise control across high and low settings is delivered through the halo-illuminated cooktop dials. The ovens have true convection and electronic oven control for precise and consistent temperatures.
- Consistent Broiling
- The Dual Fuel Range broiler provides an even heat that covers a very large surface area - perfect for browning a fully loaded oven tray.
- Easy To Clean
- The Dual Fuel Range oven has a self-cleaning function and removable side racks. The cooktop has sealed burners and an encapsulated cooking surface with a commercial-style stainless steel finish.
- Instant Visibility
- Control dials have halo-illumination glowing white - heating up; orange - temperature reached; red - self-cleaning mode. The oven is illuminated by two powerful incandescent lights.
- Cooking Flexibility
- The cooktop is designed for easy access to any burner, with grates you can smoothly slide pots across, while the oven cavity is large enough to allow you to cook multiple dishes at once.
- Top burner heat of 22,500 BTU, for seriously fast boiling
- Convection oven with 4 cu ft total capacity
- Non-tip full-extension shelves for safe removal of hot dishes
| Accessories (sold separately) | |
| Square handle option | AH-R30 |
| Burner ratings | |
| Maximum burner power | 22500 BTU |
| Power back left | 18500BTU |
| Power back right | 18500BTU |
| Power front left | 22500BTU |
| Power front right | 18500BTU |
| Total cooktop power | 78000 BTU |
| Capacity | |
| Shelf positions (main oven) | 5 |
| Total capacity (main oven) | 4L |
| Cleaning | |
| Controls | |
| Electric circuit | 4 wire |
| Gas Requirements | |
| Fitting and pipe | 1/2 NPT, min. 5/8 " flex line |
| Supply Pressure (natural gas) | 6 " to 9" W.C |
| Oven features | |
| Oven functions | |
| Number of functions | 6 |
| Oven performance | |
| Bake power | 3500 |
| Main oven - True convection power | 2500W |
| Power requirements | |
| Rated current | 30A |
| Supply frequency | 60Hz |
| Product dimensions | |
| Depth | 29 1 / 8 " |
| Height | 35 3 / 4 - 36 3 / 4 " |
| Width | 29 7 / 8 " |
| Rangetop features | |
| Safety | |
- Top burner heat of 22,500 BTU, for seriously fast boiling
- Convection oven with 4 cu ft total capacity
- Non-tip full-extension shelves for safe removal of hot dishes
Fisher and Paykel 15% and Warranty Extension Rebate
Offer Expires: 01/01/2026 to 12/31/2026 | Must be postmarked by: 12/31/2027
Receive up to a 15% rebate and a 5 Year Warranty with purchase of qualifying Fisher and Paykel Appliances.
Download Rebate Form | |
|---|---|
| Key Features | |
Cooking Technology & Design Features |
|
| Product Type | |
Product Type |
|
Fuel Type |
|
Dual Fuel |
|
Burner Type |
|
Number of Burners/Element |
|
| Dimensions & Capacity | |
Width |
|
Depth |
|
Height |
|
First Oven Capacity |
|
| Other Features | |
Sabbath Mode |
|
Configuration |
|
Color |
|
Convection |
|
Self Clean |
|
Wifi Connected |
|
Cooking has Storage Drawer |
|
Cooking has Warning Drawer |
|
Cooking First Oven Capacity |
|
Continuous Grate |
|
Downdraft Ventilation |
|
Oven Rack Type |
|
Energy Star Rated |
|
Oven Ignition Type |
|
ADA |
|
