Series 9 Integrated Tall Single DishDrawer™ Dishwasher
Add to Cart to See Actual Price
Series 9 Integrated Tall Single DishDrawer™ Dishwasher is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Series 9 Integrated Tall Single DishDrawer™ Dishwasher
Quick Specifications
Quick Specifications
- Type : DISHWASHERS
- Style : BUILT IN DISHWASHER
- Width : 23.56"
- Height : 17.875"
- Depth : 21.75"
- Energy Star Rated : YES
- Wifi Connected : NO
- Sabbath Mode : NO
Documents
Documents
- Quick Reference guide
- Quick Start Guide
- Energy Label Integrated Single DishDrawer%E2%84%A2 Dishwasher
- Planning Guide Integrated Single DishDrawer%E2%84%A2
- User Guide DishDrawer%E2%84%A2 Dishwasher EN
- Installation Guide EN
- Data Sheet Integrated Single DishDrawer%E2%84%A2 Dishwasher
- Installation Guide FR
- Planning Guide Professional Style Dial/Handle Accessories
- Installation Guide DishDrawer%E2%84%A2 Dishwasher Venting Kit EN
Delivery
Delivery
Professional delivery and installation is available for every product we sell. We would be happy to coordinate delivery and installation for you.
Warranty
Warranty
Extended warranties are usually very inexpensive and can save you thousands in the future. Some can even cover extra costs that result, such as cost of food that spoils when your fridge dies. It's simple and inexpensive to purchase extended warranties and one of the smartest ways to protect your investment.
Appliances can be large, heavy and expensive. You probably don't have the special tools or expertise needed to fix them in a crisis. If you can spare a few thousand dollars without batting an eyelash for new appliances should they break tomorrow, don't buy a warranty. But if you're like most of us, protect yourself by purchasing inexpensive extended warranties when you buy a new product and save yourself big money in the long run.
- RECEIVE UP TO 15% REBATE
- Purchase qualifying Fisher & Paykel appliances from an authorized retailer in a single transaction between March 1, 2024 and December 31, 2024 and receive a rebate by way of a Prepaid Mastercard®. Claim by December 31, 2025.
- Knock to pause function is perfect if you miss a dish
- Six wash programs, as well as additional Quick wash, Sanitize and Extra Dry options
- Built-in water softener improves wash performance by reducing unwanted minerals in the water
- Customize with your own kitchen cabinetry or purchase our stainless steel door panel accessory
| Accessories (included) | |
| Accessories (sold separately) | |
| Door panel recessed handle matte black glass | ADDD24STZB |
| Door panel recessed handle stainless steel | ADDD24STNX |
| Door panel stainless steel | ADDD24STPX |
| Handle kit Classic | AHCL-DDDW-24X |
| Handle kit Contemporary round, aluminium | AHS-OBDD-60S |
| Handle kit Contemporary square fine, aluminium | AHD5-OBDD-60SX |
| Handle kit Contemporary square fine, black | AHD5-OBDD-60SB |
| Handle kit Contemporary square, aluminium | AHD3-OBDD-60S |
| Handle kit Professional round flush | AHP3-DWDD-SX |
| Handle kit Professional round flush, Brass off-stands | AHP3DDDW24BA |
| Handle kit Professional round flush, Dark Copper off-stands | AHP3DDDW24DC |
| Capacity and loading | |
| Accommodates round plates up to | 12.25 " |
| Place settings | 7 |
| Consumption | |
| Energy usage | 152kWh/year |
| In-use energy carbon emissions estimate Carbon Emissions Info | 53.6kgCO2e/year |
| Water usage (per wash cycle) | 1.79 gal |
| Controls | |
| Features | |
| Motor type | BLDC |
| Performance | |
| Noise emissions | 43dBA |
| Power requirements | |
| Amperage | 5A |
| Electric circuit | 3 wire |
| Rated current | 15A |
| Supply frequency | 60Hz |
| Supply voltage | 100 - 120V |
| Product dimensions | |
| Depth | 21 3 / 4 " |
| Height | 17 7 / 8 " |
| Width | 23 9 / 16 " |
| Safety and compliance | |
| Wash Program Modifiers | |
| Wash modifiers | 3 |
| Wash Programs | |
| Wash programs | 6 |
| Water connection | |
| Water pressure | 100kPa - 1000kPa |
| Water supply | 3 / 8 " to suit Male Compression Fitting |
